DECOSTAR 51 PRO 35 W 12 V 10° GU5.3

Product benefits
  • Brilliant accent lighting
  • Significantly lower CO2 emissions compared to standard version
  • Constant luminous intensity and constant color location throughout the lifetime
  • Approved for use in open luminaires (to IEC 60598-1)
  • UV filter
  • Contains no mercury
View all details
Product data sheet

PRODUCT DETAILS

Electrical data

Nominal wattage 35 W
Construction wattage 35.00 W
Nominal voltage 12 V
Claimed equiv. conventional lamp power 50 W
Power factor λ 1.00

Photometrical data

Luminous intensity 11000 cd
Luminous flux 800 lm
Nominal useful luminous flux 90° 620 lm
Luminous efficacy 22 lm/W
Lumen main.fact.at end of nom.life time 0.75
Light color (designation) Warm White
Color temperature 3000 K
Color rendering index Ra 100
Light color 1030
Rated peak intensity 11000 cd
UV protection Yes

Light technical data

Beam angle 10 °
Warm-up time (60 %) 0.00 s
Starting time 0.0 s

Dimensions & Weight

Overall length 45.00 mm
Diameter 50.7 mm
Maximum diameter 51 mm
Product weight 31.6 g

Lifespan

Number of switching cycles 125000

Additional product data

Base (standard designation) GU5.3
Mercury content 0.0 mg
Mercury-free Yes
Design / version Reflector

Capabilities

Dimmable Yes
Burning position Any

Certificates & Standards

Energy efficiency class G
Energy consumption 38.00 kWh/1000h

Country-specific categorizations

ILCOS HRGS//UBIB-35-12-GU5.3-51/10
Order reference 48865 ECO SP

Energy labelling regulation data acc EU 2019/2015

Lighting technology used OTHER
Non-directional or directional DLS
Mains or non-mains NMLS
Light source cap-type (or other electric interface) GU5.3
Connected light source (CLS) No
Color-tuneable light source No
Envelope No
High luminance light source No
Anti-glare shield No
Correlated colour temperature type SINGLE_VALUE
Length 46.00 mm
Height 50.7 mm
Width 50.7 mm
Chromaticity coordinate x 0.437
Chromaticity coordinate y 0.404
Beam angle correspondence NARROW_CONE_90
EPREL ID 1337692
Model number A34899C,A34899C

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Brilliant accent lighting
  • Significantly lower CO2 emissions compared to standard version
  • Constant luminous intensity and constant color location throughout the lifetime
  • Approved for use in open luminaires (to IEC 60598-1)
  • UV filter
  • Contains no mercury
Areas of application
  • General illumination
  • Kitchen lighting
  • Dining table lighting
  • Mirror lighting
  • Workplace lighting
  • Shops
  • Restaurants, hotels and similar prestigious applications
Product features
  • Average life: 5,000 h
  • 100 % dimmable
  • Color rendering index Ra: 100
  • Color temperature: 3,000 K
  • Diameter: 51 mm
  • Deco cover
  • IRC technology
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4050300516592 Folding box
1		 58 mm x 46 mm x 46 mm 38.00 g 0.12 dm³
4050300533889 Shipping box
20		 140 mm x 123 mm x 208 mm 836.00 g 3.58 dm³
Product image: white background, diagonal
323682_DECOSTAR 51 IRC TIF (21.43 MB)
Product line drawing with letters
25559_DECOSTAR 51 ENER GY SAVER SVG (7.63 KB)
Product line drawing, front, no dimensions
325055_DECOSTAR 51 ENE RGY SAVER SVG (4.48 KB)
Energy label
EL-4050300516592-A3489 9C PDF (21.81 KB)
Logos and pictos
G left SVG (2.41 KB)
Logos and pictos
G left BW SVG (1.07 KB)
Logos and pictos
G right SVG (2.4 KB)
Logos and pictos
G right BW SVG (1.06 KB)
Spectral power distribution
349622_HAL_DICRO_AK_IR C SVG (51.54 KB)
EAN SEG number STK number EFO number ELDAS number
4050300516592 8326920 4739656 3720231 940394113
