Phase out


L 70 W/840

Product benefits
  • Proven lamp technology
View all details
Product data sheet

PRODUCT DETAILS

Electrical data

Nominal wattage 70 W
Construction wattage 70.00 W
Nominal voltage 126 V
Nominal current 685 mA

Photometrical data

Luminous flux 6200 lm
Luminous efficacy 89 lm/W
Light color (designation) LUMILUX Cool White
Color temperature 4000 K
Color rendering index Ra 80
Light color 840
Rated LLMF at 2,000 h 0.96
Rated LLMF at 4,000 h 0.95
Rated LLMF at 6,000 h 0.94
Rated LLMF at 8,000 h 0.92
Rated LLMF at 12,000 h 0.91
Rated LLMF at 16,000 h 0.90
Rated LLMF at 20,000 h 0.89

Dimensions & Weight

Overall length 1778.00 mm
Length with base excl. base pins/connection 1764 mm
Diameter 28.00 mm
Tube diameter 26 mm
Product weight 214.00 g

Lifespan

Service life 18000 h 1)
Rated lamp survival factor at 2,000 h 1.00
Rated lamp survival factor at 4,000 h 1.00
Rated lamp survival factor at 6,000 h 1.00
Rated lamp survival factor at 8,000 h 1.00
Rated lamp survival factor at 12,000 h 0.99
Rated lamp survival factor at 16,000 0.90
Rated lamp survival factor at 20,000 h 0.50
Lifespan B50 20000 h

1) With preheat ECG

Additional product data

Base (standard designation) G13
Mercury content 3.1 mg

Capabilities

Dimmable Yes

Certificates & Standards

Energy efficiency class G
Energy consumption 70.00 kWh/1000h

Country-specific categorizations

ILCOS FD-70/840-E-G13-26/1800
Order reference L 70W/840

Energy labelling regulation data acc EU 2019/2015

Lighting technology used OTHER_FL
Non-directional or directional NDLS
Mains or non-mains NMLS
Light source cap-type (or other electric interface) G13
Connected light source (CLS) No
Color-tuneable light source No
Envelope No
High luminance light source No
Anti-glare shield No
Correlated colour temperature type SINGLE_VALUE
Claim of equivalent power No
Length 1778.00 mm
Height 28.00 mm
Width 28.00 mm
Chromaticity coordinate x 0,380
Chromaticity coordinate y 0,380
Beam angle correspondence SPHERE_360
EPREL ID 546375
Model number AC34122

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals 0 mg
Quantity of rare earths 0 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Proven lamp technology
Areas of application
  • Public buildings
  • Office lighting
  • Industry
  • Shops
  • Supermarkets and department stores
  • Street lighting
  • Outdoor applications only in suitable luminaires
Product features
  • Very good lumen maintenance: 90 % throughout the service lifetime of the lamp
  • Good color rendering index
  • Dimmable
Safety advice
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4008321003959 Sleeve
1		 28 mm x 28 mm x 1,795 mm 302.80 g 1.41 dm³
4008321003966 Shipping box
25		 1,820 mm x 148 mm x 145 mm 8059.00 g 39.06 dm³
Declarations of conformity
EC Declaration of Conf ormity - 2021 9C1-4076 853-EN-00 - T8 L 70W PDF (99.87 KB)
Product image: white background, diagonal
313063_LUMILUX T8 XT / LUMILUX T8 XXT TIF (2.8 MB)
Product line drawing with letters
324360_FLUORESCENT LAM P (BASIC T8/LUMILUX T8 ) G13 BASE SVG (5.67 KB)
Energy label
EL-4008321003959-AC341 22 PDF (21.56 KB)
Logos and pictos
G left SVG (2.41 KB)
Logos and pictos
G left BW SVG (1.07 KB)
Logos and pictos
G right SVG (2.4 KB)
Logos and pictos
G right BW SVG (1.06 KB)
Spectral power distribution
349615_FL_840 PNG (92.9 KB)
EAN STK number EFO number
4008321003959 4930305 3860920
