Nominal wattage	70 W
Construction wattage	70.00 W
Nominal voltage	100…240 V
Operating mode	AC Mains, Conventional control gear (CCG)
Claimed equiv. conventional lamp power	250 W
Nominal current	750 mA
Type of current	AC
Operating frequency	50/60 Hz
Mains frequency	50/60 Hz
Total harmonic distortion	< 20 %
Power factor λ	0.90

Luminous flux	12000 lm
Nominal useful luminous flux 90°	12000 lm
Luminous efficacy	171 lm/W
Light color (designation)	Cool White
Color temperature	4000 K
Color rendering index Ra	≥80
Light color	840

Ambient temperature range

-20…+50 °C

Number of switching cycles

100000

Base (standard designation)	E40
Mercury content	0.0 mg

Dimmable

Type of protection	IP65
Standards	CB
Photobiological safety group acc. to EN62778	RG1

Order reference

HQLLED 70W/840

Light source cap-type (or other electric interface)	E40
Length	270.00 mm
Height	110.00 mm
Width	110.00 mm

Minimum rate of recycled material in packaging	80 % ¹⁾
Minimum percentage of recycled content in the product	0 % ¹⁾
Product recyclability	Mostly recyclable product ¹⁾
Packaging recyclability	Mostly recyclable packaging ¹⁾
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	No

¹⁾ According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits

Areas of application

Product features

Replacement for HQL: Suitable for operation with conventional control gear (CCG) for HQL or 100-240V mains
Replacement for other HID: Suitable for operation with line voltage without control gear
Power factor: 0.9
Type of protection: IP65
High surge protection: up to 4 kV (L-N)

Safety advice

The bulb may be larger and heavier than the replaced bulb. Before installation it must be checked, if the luminaire and especially the holder is capable of carrying the weight of the lamp. If possible, please install the safety rope included in the package containing the lamp for the types 37W E40 and 70W E40.
Not suitable for operation with ignitors.
Operation on the capacitor can lead to a reduction of the power factor of the system.
When installed horizontally, the t_c point of the lamp is located on the top side of the lamp.
Use in tight luminaires and luminaires with tight reflectors not recommended.
